10kg payload surveillance drone with 85min flight time, quick plug-and-play folding structure, intelligent flight control with auto-return, low-voltage alarm, loss-of-control protection. Ideal for disaster detection, border patrol, search & rescue, power line inspection, and forest fire prevention.
| Size | Unfold size | L1625×W985×H505±10mm |
| Symmetrical motor wheelbase | 1265±10mm | |
| Propeller | 732±5mm | |
| Maximum wingspan | 1997±10mm | |
| Fuselage height | 515±10mm | |
| Package | L915×W500×H445±10mm | |
| Weight | Arms | 2300±20g |
| Center plate | 1800±20g | |
| N.W excluding battery | 4100±20g | |
| Aluminum box + packing material | 17.5±0.1Kg | |
| Battery | 3850±50g | |
| Standard task payload | ≤5Kg | |
| Single mount point load bearing | ≤4kg | |
| Max task payload * | ≤10kg (Balanced mounting) | |
| Max take-off weight | 18Kg |
85 Minutes Maximum Flight Time – Extended endurance for long-duration surveillance and inspection missions.
10kg Payload Capacity – Carries various mission payloads including cameras, sensors, and specialized equipment.
Quick Plug-and-Play Structure – Easy folding and portability for rapid deployment in the field.
All-Weather Operation – Excellent wind resistance and rain-resistant design for harsh environments.
High-Altitude Capable – Reliable performance in elevated terrain and mountain operations.
Intelligent Flight Control System – Low-voltage alarm, loss-of-control protection, and automatic return-to-home.
Precision Manual Control – Fine-tuned handling for operator-directed missions.
Autonomous Flight Route Planning – Pre-programmed missions for consistent, repeatable operations.
Efficient Power System – Optimized energy management for maximum endurance.
Intelligent Control Battery – Smart battery management for safety and reliability.
Ideal for:
✔ Disaster detection and damage assessment
✔ Technical investigation and crime scene documentation
✔ Border patrol and coastal surveillance
✔ Search and rescue operations
✔ Road monitoring and traffic management
✔ Geographic surveying and mapping
✔ Power line and infrastructure inspection
✔ Forest fire prevention and early detection
✔ Earthquake relief and humanitarian response
