700kg-Class Coaxial Twin-Rotor Unmanned Helicopter

700kg-class coaxial twin-rotor unmanned helicopter – 300kg payload, 6500m service ceiling, 5300m takeoff altitude, 5h endurance, Level 7 wind resistance. Medical capsule capable. For mountain rescue, maritime rescue, large-range patrol, and material transport.



Length

7.2m

Max Flight Speed

190km/h

Width

1.9m

Max Takeoff & Landing Altitude

5300m

Height

2.4m

Service Ceiling

6500m

MTOW

1000kg

Endurance

5h

Max Payload

300kg

Wind Resistance

Level 6 (takeoff & landing),

Level 7 (in flight)

Cruise Speed

(120-140)km/h

Rain Resistance

Moderate Rain



  • Medical Capsule Capable – Configured to carry a medical evacuation capsule. Mountain rescue. Maritime rescue. Battlefield casualty evacuation.

  • 300kg Maximum Payload – Heavy cargo, medical capsules, sensors, or multi-mission equipment.

  • 6,500m Service Ceiling – Operates at extreme altitudes – Himalayan, Andean, and high plateau missions.

  • 5,300m Takeoff & Landing Altitude – Takes off from the world's highest airports and mountain bases.

  • 190km/h Maximum Speed – Rapid response for rescue and patrol missions. 120-140km/h efficient cruise.

  • 5-Hour Endurance – Extended missions for large-range patrol and search operations.

  • Coaxial Twin-Rotor Configuration – Compact rotor diameter. No tail rotor. Superior hover stability.

  • Level 6 Takeoff/Landing | Level 7 In-Flight Wind Resistance – Operates in challenging wind conditions.

  • Moderate Rain Resistance – All-weather mission capability.

  • Stable in Complex Environments – Handles gusts, high/low temperatures, load changes, and center-of-gravity shifts.

  • Compact Structure – Small rotor diameter for its class – fits in transport helicopters and cargo aircraft.

Ideal for:
✔ Mountain search and rescue (SAR)
✔ Maritime rescue and casualty evacuation
✔ Large-range inspection and patrol
✔ Material transport to remote high-altitude locations
✔ Medical evacuation from inaccessible terrain
✔ Border patrol and surveillance
✔ Disaster response and humanitarian aid
